Natural gas exploration downhole equipment cable
Natural gas exploration downhole equipment cables have low loss and high insulation voltage, and are key components in the process of extracting natural gas from underground reservoirs. These cables are subjected to harsh environments, including high temperatures, pressure and corrosive conditions.
GET A QUOTE
Applications
Natural gas exploration downhole equipment
Product Features:
1. Low loss.
2. Three layers of insulation protection, no pinholes;
3. With high insulation voltage, insulating tape and insulation layers can be omitted and the volume can be reduced;
4. The coil is easy to roll, because the surface has a very low friction coefficient, which provides opportunities for automatic high-speed winding.
5. Higher temperature level and excellent performance.
Technical Parameters
Conductor Size | Standard outer diameter | Maximum outer diameter | Max Conductor Resistance(Ω/km) | |
---|---|---|---|---|
AWG | Outer diameter (mm) | |||
32 | 0.2 | 0.52 | 0.56 | 614 |
30 | 0.26 | 0.55 | 0.59 | 359 |
28 | 0.32 | 0.59 | 0.63 | 237 |
26 | 0.4 | 0.64 | 0.68 | 152 |
25 | 0.5 | 0.72 | 0.76 | 95.1 |
23 | 0.6 | 0.82 | 0.86 | 66.1 |
22 | 0.64 | 0.85 | 0.89 | 56.3 |
22 | 0.7 | 0.92 | 0.96 | 48.5 |
21 | 0.8 | 1 | 1.04 | 37.2 |
19 | 1 | 1.19 | 1.23 | 23.8 |
1.2 | 1.43 | 1.47 | 16.5 |
