Application:
Natural gas liquefaction equipment
Characteristic:
- Temperature resistance: -60 to 180°C
- Tinned copper
- Oxidation resistance
- High conductivity
- Ultra-low temperature resistance
- Anti-freeze and cold-resistant
- Excellent mechanical properties
Industry Standard:
- EN45545-2
Structure:
- Conductor: Tin-plated copper conductor, either 5-class or 6-class structure.
- Fire resistance: Complies with EN45545-2 R15/R16 HL3.
Selection parameter
Conductor nominal cross-section | Number of wires * core wire diameter | Conductor stranding diameter (d) | Cable outer diameter (D) | 20℃ conductor resistance | ||
---|---|---|---|---|---|---|
Min. mm | Min. mm | Min. mm | Max. mm | MJ/K m | ||
0.5 | 19×0.18 | 0.8 | 0.18 | 1.3 | 1.45 | 40.1 |
0.75 | 37×0.16 | 1 | 0.18 | 1.5 | 1.65 | 26.7 |
1 | 37×0.18 | 1.1 | 0.18 | 1.6 | 1.8 | 20 |
1.5 | 37×0.23 | 1.45 | 0.22 | 1.95 | 2.3 | 13.7 |
2.5 | 37×0.30 | 1.85 | 0.28 | 2.35 | 2.85 | 8.21 |
