Rail transit jumper cable

Rail transit jumper cables are fire-resistant, low-smoke and halogen-free and are an important part of the electrical infrastructure of railway systems, providing temporary connections between power supplies and various equipment.

GET A QUOTE

Product parameters

  • Conductor: Tinned copper conductor Category 6 construction
  • Insulation: silicone rubber
  • Rated voltage: 3.6/6.0kV
  • Dielectric strength:>8MPa
  • Cable bending radius: 6D (D cable outer diameter)
  • Operating temperature: -50°C to +150°C
  • Service voltage:300V/500V
  • Test voltage :2,500V

Optimized cable structure:
power jumper, control jumper, data jumper, comprehensive jumper

Satisfied applications
① Fire resistance ② Low smoke emission

③ Low toxicity ④ Sun aging resistance ⑤ Oil resistance

⑥ Weather resistance ⑦ Mechanical resistance

Fire resistant properties

  • EN45545-2 HL1 — HL3  Test
  • single vertical          EN60332-1-2
  • Smoke density      EN61034-2
  • toxicity              EN50305-9-2

All qualification certifications for the railway industry

  • CRCC certified enterprise
  • TS22163 (International Railway Quality Management System)
  • ISO9001 (quality system)
  • CE product certification
  • ECER118 fire protection

This titile is also available in: Arabic German Indonesian Japanese Russian Spanish Thai Vietnamese

WHY CHOOSE TST

19 quality tests before cable shipment
R&D personnel account for 42% of the company’s headcount
Support all kinds of customization, free sampling
10,000 ㎡ factory, annual production capacity of 2,000,000 meters
