Rail transit Lighting cable
Rail transit lighting cables are high temperature resistant and have a rated voltage of 600V. They are an important part of the lighting provided in various areas of the rail transit system (including passenger compartments, platforms and stations).
GET A QUOTE
Application：
Lighting system
Characteristic：
- Temperature resistance: -40°C to 125°C
- Voltage rating: 600V (test voltage of 3500V/5min)
- Meets EN50200 requirements for 30 minutes and 90 minutes
Industry Standard:
- Comply with TBIT1484.1-2017 and TJ/CL254-2013 locomotive and passenger vehicle cable requirements.
- Passes EN45545, HL1, HL2 and HL3 requirements inside and outside the vehicle.
- Comply with BS6853:1999 requirements for la, lb, and class locomotives regarding internal and external cables.
- Passed BS6853:1999 and DIN5510-2:2009 fire, smoke and toxicity tests.
- Comply with the requirements of flammability class S1~S5 in DIN5510-2:2009.
- Passed China Railway Products CRCC certification.
Structure：
- Conductor: Silver-plated copper conductor with Class 5 structure.
- Insulation: Irradiated cross-linked polyethylene.
Selection parameter
| Number of cores x nominal cross section | Conductor diameter （d） | Average thickness of insulation | Outer diameter （D） | 20℃ conductor resistance |
|---|---|---|---|---|
| Min. mm | Max.Ω/km | |||
| 2×0.75 | 1.1 | 0.4 | 6.5 | 26.7 |
| 4×0.75 | 1.1 | 0.4 | 7.2 | 26.7 |
| 2×1.0 | 1.3 | 0.5 | 7 | 20 |
| 2×1.5 | 1.5 | 0.5 | 7.2 | 13.7 |
| 3×1.0 | 1.3 | 0.5 | 7.3 | 20 |
| 2×2.5 | 1.9 | 0.5 | 8.5 | 8.21 |
| 2x2x1.0 | 1.3 | 0.5 | 10.3 | 20 |
| 3x2x0.5 | 1.1 | 0.4 | 10.2 | 40.1 |
| 6x2x0.75 | 1.1 | 0.4 | 16.4 | 40.1 |
