Remote monitoring system cable
The remote monitoring system cable has good insulation and is resistant to ultra-high temperatures. It is an important part of the remote monitoring system and is responsible for transmitting data, control signals and power between the remote monitoring equipment and the central monitoring station.
GET A QUOTE
Industry standard
- Q31/0114000209C025-2017
Product Features
- Rated voltage: 500V
- Working temperature: -60℃~300℃ (up to 350℃ in short time)
- Conductor: nickel-plated stranded wire
- Insulation: double layer insulation
Features/Use
Remote monitoring system
Technical Parameters
Nominal cross section(mm2) | Conductor structure Root number /diameter(mm) | Insulation thickness (mm) | Outside diameter control (mm) | conductor DC resistance (Q/km) |
---|---|---|---|---|
2.2±0.2 | 200 | |||
1.25 | 40/0.20 | 0.4 | 2.4±0.2 | 200 |
1.5 | 48/0.20 | 0.4 | 2.6土0.2 | 200 |
2.5 | 35/0.30 | 0.4 | 3.0土0.3 | 100 |
4 | 56/0.30 | 0.4 | 3.7±0.3 | 100 |
6 | 84/0.30 | 0.4 | 4.6±0.3 | 100 |
10 | 140/0.30 | 0.4 | 5.6±0.3 | 100 |
